| Part Number | DC BreakdownVo ltage(VBR)@100V/s (V) | Tolerance of VBR(V) | Impulse Spark-over Voltage@1KV/μs (V) | Arc Voltage (Va)@1A(V) | Impulse Discharge Current@8/20μs (kA) | Insulation Resistance (GΩ) | @ DC (V) | Capacitance CO 0.5VDC@1MHZ(pF) | Size L*W*H(mm) | 搜索 | |
| B3D090L-C | 90 | 68-112 | ≤700 | ～8 | 5 | ≥1 | 100 | ≤1.5 | 7.8x5.0x6.0 | ||
| B3D230L-C | 230 | 184-276 | ≤800 | ～8 | 5 | ≥1 | 100 | ≤1.5 | 7.8x5.0x6.0 | ||
| B3D420L-C | 420 | 336-504 | ≤950 | ～8 | 5 | ≥1 | 100 | ≤1.5 | 7.8x5.0x6.0 | ||
| B3D470L-C | 470 | 360-560 | ≤950 | ～8 | 5 | ≥1 | 100 | ≤1.5 | 7.8x5.0x6.0 | ||
| B3D090M-C | 90 | 72-108 | ≤600 | ～10 | 10 | ≥1 | 100 | ≤1.5 | 7.8x5.0x6.0 | ||
| B3Q420 | 420 | 360-560 | ≤950 | ～20 | 2 | ≥1 | 100 | ≤1 | 6.8x3.5x3.5 | ||
| B3Y471M | 470 | 360-540 | ≤1000 | ～8 | 1 | ≥1 | 100 | ≤1.5 | 6.2x3.2x2.3 | ||
| BXD3000SA03M | 3000 | 2400-3600 | ≤2500 | ~35 | 3 | ≥1 | 100 | ≤500 | 8.8x6.2x8.5 | ||
| B3A420 | 470 | 360-560 | ≤950 | ?10 | 2 | ≥1 | 100 | ≤1.0 | 4.2x2.7x3.9 | ||
| B3D230L-CD | 230 | 200-380 | ≤800 | ?15 | 5 | ≥1 | 100 | ≤1.5 | 7.8x5.0x6.0 | ||
| B3D470L-1 | 470 | 350-500 | ≤950 | ?8 | 5 | ≥1 | 100 | ≤1.5 | 7.3x5.0x5.0 | ||
| BXD3000SA03M03 | 3000 | 2400-3600 | ≤2500 | ?35 | 3 | ≥1 | 100 | ≤500 | 11.8x8.3x10.8 |
